OVERVIEW
POLO XL : Independent Driven Technology, Faster! Better! Sharper!
Polo XL, the high speed industrial grade solvent printer is built on a heavy-duty structure. The independent drive technology is renowned for its high speed, high quality output and reliability, as well as low running cost. In Polo XL solvent printer the independent drive technology drives each nozzle independently to achieve high speed production up-to 2818 sqft./hr. Polo XL is supported by IR-based effective evaporative drying system, to meet high-volume requirements. This solvent printer has 3.2 meter roll-to-roll capability and is based on an industrial-grade jetting assembly which ensures accuracy at high speed. This is the best solution for diverse indoor/outdoor applications.
FEATURES
Polo XL : FEATURE-RICH TO BOOST YOUR BUSINESS
ColorJet’s Polo XL Series is a marvel of engineering from the special R&D team of ColorJet, which usually works on high-end machines; this new gem from the ColorJet’s house of innovation revolutionizes the industries standards of revenue generation for our customers.
Polo XL Series is specially designed to handle various media, from low GSM to thick paper-backed self-adhesive vinyl.
This high-speed printer not only handles a variety of difficult media with charm but also prints them like no other printer in the segment, Crystal Sharp Images printing at such high speed is the new barrier broken by the R&D of the ColorJet.
Zero maintenance the new design objective language version 7.0 is utilized fully in this XL series of Polo; spare parts and consumables are fully utilized under this new manufacturing & design setup.
SPECIFICATION
Polo XL |
|||||||
Models |
GB4424 |
GB8424 |
GB4412 |
GB8412 |
|||
| Printing Technology | Drop-on-demand, Piezo electric inkjet |
||||||
| No. of Print Heads | 4 Head |
8 Head |
4 Head |
8 Head |
|||
| Print Heads | Greyscale Industrial Grade Jetting Assemblies |
||||||
| Media | Width | 3300 mm |
|||||
| Thickness | Maximum 3.0 mm with liner |
||||||
| Roll Outer Diameter | Maximum 352mm |
||||||
| Roll Weight | Maximum 150 kgs |
||||||
| Core Diameter | 76.2mm, 50.8mm |
||||||
| Types | SAV, PAV Banner, Backlite Film, Window Film, Fabric (Solvent Base) |
||||||
| Printing Width | Maximum 3200mm |
||||||
| Inks | Types | Solvent based pigment inks |
|||||
| Color | 4 Colors
|
||||||
| Printing Resolution (dots per inch) | Maximum up to 1440 dpi |
||||||
| Distance Accuracy | Error of less than ±0.3 % of distance travelled, or ±0.3 mm, whichever is greater |
||||||
| Media Heating System | Pre Heater and post-heater, setting range for the preset temprature: 30 to 60℃. Dryer setting range for the preset temperature : 30 to 60℃ |
||||||
| Connectivity | High speed USB |
||||||
| Power Requirements | AC 220V , 40A(±10%),50Hz |
||||||
| Dimensions ( Printer only) | 4960mm x 950mm x 1580mm (LxWxH) |
||||||
| RIP software | Onyx (Colorjet Edition) |
||||||
| Weight (approx. with stand) | 1500 Kgs |
||||||
| Environmental | Power ON | Temperature: 18 to 28℃ Humidity: 35 to 80%RH (non-condensing) |
|||||
| Power OFF | Temperature: 5 to 40℃ Humidity: 20 to 80%RH (non-condensing) |
||||||
KM1024i |
KM512i |
||||||
GB4424 |
GB8424 |
GB4412 |
GB8412 |
||||
Modes |
Print DPI |
Passes |
Speed (In Sq. mtr/hr) |
||||
| Mode 1 | 360x360 |
1
|
2830 |
4715 |
- |
- |
|
| Mode 2 | 360x720 |
2
|
1636 |
2744 |
- |
- |
|
| Mode 3 | 360x1080 |
3 |
1162 |
1937 |
- |
- |
|
| Mode 4 | 360x1440 |
4 |
904 |
1506 |
- |
- |
|
| Mode 5 | 360x1080 |
6 |
645 |
1076 |
- |
- |
|
| Mode 6 | 360x1440 |
8
|
516 |
861 |
- |
- |
|
| Mode 1 | 360x360 |
2
|
- |
- |
1614 |
2818 |
|
| Mode 2 | 360x540 |
3
|
- |
- |
1093 |
2000 |
|
| Mode 3 | 360x720 |
4
|
- |
- |
806 |
1476 |
|
| Mode 4 | 720x720 |
4
|
- |
- |
521 |
930 |
|
| Mode 5 | 720x1080 |
6
|
- |
- |
327 |
640 |
|
| Mode 6 | 720x1440 |
8
|
- |
- |
249 |
490 |
|
